Case 1188 Excavator Service Manual
Quality Manual

Case 1188 Excavator Service Manual

Regular price $109.99 Sale price $200.00 Unit price per

Download Case 1188 Excavator Service Manual

We Offers manuals high quality images, diagrams, instructions to help you to operate, maintenance, diagnostic, and repair your truck. This document is printable, without restrictions, contains searchable text, bookmarks, crosslinks for easy navigation.

This professional-grade manual contains service procedures for the Case 1188 excavators. This high definition manual is searchable, printable and has a table of contents. View the service manual on your computer or print off detailed service and maintenance instructions with illustrations as needed.

Please note the engine/fuel repair manual and schematic set are sold separately.

Topics in the Case 1188 Excavator Repair Manual:

GENERAL INFORMATION
Safety, General Information and Standard Torque Settings
Specifications (Crawler Excavators)
Specifications (Wheeled Excavators)

ENGINE
Engine removal and installation
ENGINE REPAIR MANUAL SOLD SEPARATELY

ELECTRICAL SYSTEM
Starter motor
Alternator
Anti – start device tool
SCHEMATIC SET SOLD SEPARATELY

UNDERCARRIAGE
Set of tracks (Crawler excavators)

DRIVE TRAIN
Travel reduction gear and brake (Crawler excavators)
Swing reduction gear and brake
Front axle and service brake (Wheeled excavators)
Rear axle and service brake (Wheeled excavators)
Gearbox and parking brake (Wheeled excavators)
Twin Wheels

UNDERCARRIAGE HYDRAULICS
Hydraulic travel motor (Mono-speed crawler excavators)
Hydraulic travel motor (Two-speed crawler excavators)
Hydraulic travel motor (Two-speed wheeled excavators)
Travel control valve
Travel, stabilizer or dozer blade control valve (Wheeled excavators)
Steering, stabilizer, dozer blade and axle locking cylinders (Wheeled excavators)

UPPERSTRUCTURE HYDRAULICS
Hydraulic swivel (Crawler Excavators)
Hydraulic swivel (Wheeled Excavators)
Hydraulic pumps
Attachment control valve
Swing control valve
Rotary control valve (Orbitrol) (Wheeled excavators)
Hydraulic swing motor and safety forced-feed block
Attachment and swing control block (Control lever)
Travel and option control block (Pedal valve, wheeled excavators)
Travel hand control block (Inching, crawler excavators)
Direction of travel inverter control block (Inching, wheeled excavators)
Travel control block (Wheeled excavators)
Brake unit (Wheeled excavators)
Parking brake solenoid valve
Electro-control valve block (Crawler excavators)
Electro-control valve block (Wheeled excavators)
Attachment cylinders
Safety valves
Large format hydraulic and electrical schematic (Crawler excavators)
Large format hydraulic and electrical schematic (Wheeled excavators)

UPPERSTRUCTURE
Upperstructure and turntable bearing
Cab

Covers: Case 1188 Crawler/Wheeled Excavator
Pages: 648
Format: PDF
File size: 50mb
Compatibility: Windows/Mac/Tablet
Note: Instant digital download only – no printed copy or CD-ROM media.
